United Arab Emirates · Engineering Deliverable

Arc Flash Study UAE.
The report,
the labels,
the proof.

The IEEE 1584-2018 incident energy calculation, the bilingual Arabic-English labels installed at every panel, the ADNOC SAES-E-005 conformance matrix, the worker training pack. An engineering deliverable for UAE plant owners, procurement teams, and EHS heads who need a study that satisfies ADNOC operating-company audit · signed by a Chartered Engineer (CEng MIE FIE).

Scope Your Arc Flash Study → See the Workflow

VB engineer at an arc flash compliance walkdown at a UAE brownfield plant · cinematic field shot

VB field team at an arc flash compliance task at a UAE plant

Bilingual · ADNOC spec

• LIVE INSTALLATION · INCOMER-1

Engineered label on red INCOMER-1 panel

Blue arc-rated suit · orange hood · bilingual label affixed under witness signature

UAE Standards Stack

ADNOC SAES + IEEE 1584 + NFPA 70E.
The three layers your auditor reads.

An Arc Flash Study that satisfies UAE audit is not a single-standard document. It is a layered compliance proof against ADNOC operating-company specifications, IEEE 1584-2018 calculation methodology, and NFPA 70E 2024 work-practice rules for energised work, PPE selection, and labelling. Every deliverable opens with the conformance matrix that calls each section to the relevant clause.

ADNOC SAES-E-005

Arc Flash Risk Assessment

Prime UAE compliance standard for ADNOC operating companies. References IEEE 1584 methodology, mandates bilingual labelling, sets 5-year revalidation cycle.

IEEE 1584-2018

Arc Flash Calculation

The current calculation standard. 2002 method retired. Incident energy at every working position, arc flash boundary, restricted approach distance.

NFPA 70E 2024

Electrical Safety in the Workplace

The work-practice standard ADNOC SAES-E-005 cross-references. Energised work permits, PPE category tables, approach boundaries, training cycle, label format. The auditor reads the PPE tables straight from here.

DEWA Distribution Code

LV Connection Compliance

For DEWA-fed industrial customers in Dubai · Jebel Ali, Mussafah, KIZAD. Connection-side arc flash audit per DEWA standard.

Bilingual labels · what your auditor sees on every panel

Same calculation. Two languages. One audit-ready label.

ADNOC operating-company specifications mandate bilingual Arabic-English labelling on every switchgear, MCC, and transformer. Below are two real labels from a VB Engineering deliverable. The English NFPA 70E format. The Arabic WARNING format. Same incident-energy data. Equal weight. Affixed under witness signature.

English NFPA 70E DANGER arc flash label · DOUBLE BREAK ISOLATOR_1 · 1627.85 cal per cm squared

EN · NFPA 70E

DOUBLE BREAK ISOLATOR_1
1627.85 cal/cm² · Dangerous

Arabic WARNING arc flash label · BUS-600 KVAR APFC Panel · 4.33 cal per cm squared · ADNOC SAES format

AR · ADNOC SAES

BUS-600 KVAR APFC
4.33 cal/cm² · Category 1

Print-ready. Site-installed. Witness-signed.

Every label carries: DANGER ARC FLASH HAZARD (English top, Arabic bottom · equal weight per ADNOC specification), ATPV cal/cm² value, arc flash boundary distance, restricted approach distance, PPE category, equipment ID, study date.

Labels are printed at our Hyderabad facility, shipped to UAE, installation supervised by our Dubai team. Operator option to print locally with our master files. Five-year revalidation written into the AMC retainer.

What you receive

Six deliverables. One Chartered Engineer signature.

An Arc Flash Study from VB Engineering is not a software report PDF. It is a documented engineering deliverable structured for ADNOC HSE audit, insurer review, and procurement file. Every section signed CEng MIE FIE.

Power System Modelling and Arc Flash Risk Analysis · the ETAP DigSILENT model that produces the incident energy report

IEEE 1584-2018 Incident Energy Report

Incident energy at every working position calculated against IEEE 1584-2018 method (the 2002 method is retired in our practice). Arc flash boundary, restricted approach distance, PPE category per ATPV. Calculated in ETAP or DigSILENT, hand-verified at critical buses.

ETAPDigSILENTIEEE 1584-2018

Engineered VB warning label installed on HVAC VIVARIUM LAB 1600A panel showing 7.1 cal per cm squared with arc flash and shock boundary annotations

Bilingual Arabic-English Labels

Print-ready arc flash warning labels in bilingual format · English on top, Arabic below, both equal-weight per ADNOC operating-company specification. ATPV value, working distance, PPE category, equipment ID. Mounted on every switchgear, MCC, transformer.

Bilingual AR-ENADNOC spec

VB Engineering full certifications stack · ISO 45001 · ISO 9001 · chartered-engineer credentials referenced on every signed deliverable

SAES-E-005 Conformance Matrix

Section-by-section mapping of the study to ADNOC SAES-E-005 clauses. Front-of-report submission template. Format pre-cleared with multiple ADNOC operating companies · auditors recognise the layout.

SAES-E-005Audit-ready

Data Verification and SLD Preparation · field walkdown data reconciled against legacy single line diagram before any calculation begins

SLD Reconciled to As-Found

Single-line diagram verified against the as-installed equipment via supervised walkdown. Drift from legacy SLD logged. The calculation accuracy is constrained by SLD accuracy · we deliver both. Client engineer co-signs reconciliation.

As-found SLDClient-verified

$Data Collection and On-Site Survey · nameplate, CT and PT ratio, breaker trip-unit settings logged on tablet during the walkdown phase$ 05

Walkdown + Field Data Pack

Nameplate verification, CT/PT ratio confirmation, breaker trip-unit settings, cable run measurements. Every equipment item photographed and tablet-logged. The basis-of-design archive that survives staff turnover.

Field-verifiedPhoto-documented

$Our methodology summary · the engineering audit trail that every Arc Flash Study deliverable opens with$ 06

Executive Summary + Action Register

2-page executive summary for HSE Head sign-off. Action register with categories (engineering control, PPE upgrade, procedure change, training), priority ranking, responsible discipline, target dates. The format your ADNOC HSE auditor reads first.

Exec-readyAction tracker

The Workflow

Seven engineering steps. Six to eight weeks.

The Arc Flash Study workflow is methodical, technical, and signed at every gate. We are not delivering a PDF · we are delivering an engineering audit trail.

STEP 01

Site walkdown + as-found verification

Physical walkdown of every switchgear, MCC, transformer. Nameplate verification, CT/PT ratio confirmation, breaker trip-unit settings logged on tablet. Legacy SLD reconciled to field. Drift documented per equipment. Client engineer accompanies walkdown.

2-3 days siteSenior Engineer led

Site walkdown + as-found verification · VB engineer and client engineer reviewing the plant single-line diagram in the UTILITY MCC room · client-co-signed reconciliation

STEP 02

SLD reconciliation + client sign-off

Walkdown data plotted against the client SLD. Every drift logged. Client engineer co-signs the reconciled SLD before any calculation begins. This is the input-layer discipline that decides accuracy of every downstream number.

3-5 days deskClient co-signed

Complete VB Engineering 40 CAL per cm squared arc flash suit ensemble · hood face shield gloves boots

STEP 03

System modelling in ETAP or DigSILENT

Software model built from verified as-found data. Source impedances, transformer parameters, cable lengths and impedances, motor contributions, generator data. Every bus identified, every protective device modelled. IEC 60909 fault calculations cross-validated by hand at critical buses.

1-2 weeksETAP / DigSILENT

VB engineer at UAE substation HMI · system modelling input data verification

STEP 04

IEEE 1584-2018 incident energy calculation

Incident energy at every working position. Arc flash boundary distance. PPE category per ATPV value. Where incident energy exceeds 40 cal/cm², the work practice recommendation is "energised work prohibited" · documented in the report with engineering control alternatives.

1 weekIEEE 1584-2018

NFPA 70E masterclass training session for plant electrical workers · the calculation methodology explained to client

STEP 05

Bilingual label production

Print-ready bilingual Arabic-English labels generated per equipment. English NFPA 70E format on top, Arabic ADNOC-spec format below, equal weight. ATPV, boundary, PPE category, equipment ID, study date. Print at Hyderabad · ship to UAE · install under witness signature.

2 weeksEN + AR

VB Engineering arc flash field engagement at a UAE brownfield plant

STEP 06

Site installation + operator handover briefing

Arc flash warning labels (NFPA 70E format with ATPV cal/cm² value, arc flash boundary distance, restricted approach, PPE category, equipment ID) affixed at every switchgear, MCC, transformer. Dubai team supervises installation in coordinated outage windows. Witness signature per label. Operator handover briefing delivered the same day so the workforce understands every label before energising work resumes.

1-2 weeksOperator handover

VB Engineering on-site labelling at a UAE plant · arc flash label installation activity

STEP 07

Final report + Chartered Engineer signature

Signed engineering deliverable. SAES-E-005 conformance matrix front-of-report. Executive summary + action register. CEng MIE FIE signature on every section. Audit-ready, insurer-ready, ADNOC HSE-ready. Optional 5-year AMC retainer offered for recurring compliance.

1 weekCEng MIE FIE

Expert Arc Flash Risk Assessment · the final signed deliverable from VB Engineering · CEng MIE FIE signature on every section

The Proof

Field-installed. Not just calculated.

Two photographs from VB Engineering field installations. The physical proof that an Arc Flash Study from us does not end at a PDF report.

Arc Flash Boundary

Tiger-stripe boundary at 33 kV outdoor substation

Where incident energy demands a physical demarcation, we paint the boundary. Yellow and black tiger stripes at the cable pit perimeter define the energised work restricted-approach distance. No calculation in a PDF replaces this.

VB Engineering arc flash field deliverable · UAE install evidence

Installed Label

Engineered label installed on HVAC VIVARIUM LAB 1600A

7.1 cal/cm² calculated. PPE Category 2 recommended. Arc flash boundary noted at 12 inches. Shock-hazard restricted-approach distance noted. Installed and witness-signed. The form the auditor opens the door and reads.

UAE Engagements

Three UAE Arc Flash Studies. Three operator profiles.

Every UAE Arc Flash Study is shaped by which operating-company specification governs. Below: three landmark UAE engagements · one per operating-specification pattern.

VB Engineering arc flash field deliverable · UAE engagement case 1

Landmark upstream gas facility · UAE

Gas gathering field · 33 kV ring main · 12 satellite skids

SAES-E-005 conformance audit found relay grading drift after expansion. Full reset of protection coordination plus arc flash recalculation plus bilingual label production. Reduced average incident energy at the MCC by 38%.

Outcome

ADNOC HSE pre-audit pass. Bilingual labels installed at all 12 skids in coordinated outage. Training delivered to 47 operators in EN + AR.

38%

Incident energy ↓

Weeks delivery

Marquee steel plant · UAE

Heavy steel fabrication · 11 kV DEWA connection · 4 MVA in-plant

DEWA Distribution Code compliance audit on the 11 kV intake breaker arrangement. SLD reconciliation against DEWA-approved drawings. Found breaker rating undersized at one bus, replacement specified, arc flash baseline restored.

Outcome

DEWA connection compliance restored. Breaker upgrade specification accepted by operator. Labels installed plant-wide. AMC retainer signed.

11 kV

DEWA intake

Weeks delivery

Prominent petrochemical complex · UAE

Polyolefins train · 132 kV intake · 11 kV distribution

Insulation coordination review triggered by lightning event on the 132 kV bus. Arc flash recalculation downstream of new surge arrester rating. Bilingual labels on Zone 1 process bays where energised work boundary changed.

Outcome

Operating company HSE accepted revised energised-work-permit boundaries. 5-year recertification calendar aligned to operator HSE management system review cycle.

132 kV

Intake voltage

Weeks delivery

UAE Buyer Questions

Procurement and engineering questions, answered.

Are you ADNOC-AVL pre-qualified?

We hold pre-qualification with multiple ADNOC operating companies for power systems and process safety engineering. Specific opcode-level approvals depend on the operating company · we provide current pre-qualification status on request before tender submission. For non-ADNOC UAE work (DEWA-connected industrial, Jebel Ali Free Zone, KIZAD), no operator pre-qualification is required.

How does ADNOC SAES-E-005 compare to NFPA 70E?

SAES-E-005 references IEEE 1584 methodology (same calculation engine as NFPA 70E). The differences are administrative · ADNOC SAES-E-005 mandates bilingual Arabic-English labels (NFPA 70E is English-only), specifies 5-year revalidation, and requires the conformance matrix front-of-report. Where the operator references both standards (typical for multinational JVs in Ruwais), we deliver a dual-track package.

Can the study be conducted during plant operations?

Yes. The walkdown, data collection, and software modelling phases require no shutdown · they run during normal operations. Label installation requires brief access to each equipment item (5-10 minutes) coordinated with operations supervisor. Worker training delivered between shifts. Full study end-to-end with no plant shutdown is standard delivery.

What is the typical timeline for a UAE Arc Flash Study?

For a 11 kV / 33 kV industrial site (typical Jebel Ali, Mussafah, KIZAD): 6 weeks end-to-end. For a 132 kV ADNOC operating-company facility (Ruwais petrochem, ADNOC onshore gas gathering): 8 weeks. For a multi-train operating-company complex: 10-14 weeks split across phased outage windows.

Do you deliver in operator-preferred software format?

Yes. Default modelling is ETAP. Where the operator standardises on DigSILENT PowerFactory (typical for Aramco-aligned procurement), we deliver in DigSILENT. Where the operator standardises on PSCAD, we deliver in PSCAD. Output reports are software-agnostic PDFs with raw model files included.

What is included in the bilingual label format?

Print-ready PDF labels per equipment. Each label carries: DANGER ARC FLASH HAZARD (English top, Arabic bottom · equal weight), ATPV cal/cm² value, arc flash boundary distance, restricted approach distance, PPE category, equipment ID, study date. Labels printed at our Hyderabad facility, shipped to UAE, installation supervised by our Dubai team. Operator option to print locally with our master files.

Is the 5-year AMC retainer mandatory or optional?

Optional. The base Arc Flash Study is a one-time engineering deliverable. The 5-year AMC retainer (annual walkdown + change-impact + re-labelling on equipment changes + full re-study at year 5) is offered as a follow-on contract for operators who want continuous compliance instead of episodic re-tendering. Typical 60% of UAE customers sign the AMC for cost predictability.
