Project Description

Short circuit analysis is performed so that existing and new equipment ratings were sufficient to with stand the available short circuit current. This short circuit analysis can be done either through hand calculations or through known software like NEPLAN. Using NEPLAN we can perform short circuit studies on electrical systems in a quick time and effective manner. These short circuit studies are performed using power system software as per IEEE standards. For larger systems, these short circuit calculations to be performed for both switch gear ratings and relay settings. These short circuit calculations must be maintained and periodically updated in order to protect people and equipment. Short circuit studies are performed in NEPLAN by introducing different faults like three phase fault, single phase to ground etc. Our services include building the network drawing by collecting the data from facility and performing short circuit studies using network analysis software.
